CAT8 cables feature a dual shielding (SFTP) design that minimizes crosstalk and electromagnetic interference (EMI), supporting 25Gbps/40Gbps speeds at frequencies up to 2000MHz. Tactical connectors with metal housings and specialized shielding prevent signal leakage at connection points, making them ideal for high-electromagnetic environments such as military bases and industrial facilities with heavy machinery.
The integration of CAT8 cables with tactical Ethernet connectors creates a synergistic solution that combines high-performance data transmission with rugged environmental adaptability, specifically designed for mission-critical and harsh-environment applications.
| Description | CAT8 | Part Number | SMT-3011T8C6A-FTP |
|---|---|---|---|
| Size | RJ45 | Gold Plated | 6 µ |
| Material | Polycarbonate + Zinc Alloy | MOQ | 1000 Pieces |
| Packing | 1 Piece/PE bag, 500 pieces/Carton | Packing Size | 53×32×23cm |
| Frequency (MHz) | Return Loss Min (dB) | Attenuation Max (dB/100m) | NEXT Min (dB/100m) | PSNEXT Min (dB/100m) | ELFEXT Min (dB/100m) | PSELFEXT Min (dB/100m) |
|---|---|---|---|---|---|---|
| 1 | 20 | 1.84 | 74.3 | 72.3 | 68 | 65 |
| 4 | 23.01 | 3.69 | 65.27 | 63.27 | 55.96 | 52.96 |
| 10 | 25 | 5.89 | 59.3 | 57.3 | 48 | 45 |
| 16 | 25 | 7.51 | 56.24 | 54.24 | 43.92 | 40.92 |
| 20 | 25 | 8.43 | 54.78 | 52.78 | 41.98 | 39.98 |
| 31.25 | 23.64 | 10.64 | 51.88 | 49.88 | 38.1 | 35.1 |
| 62.5 | 21.54 | 15.36 | 47.36 | 45.36 | 32.08 | 29.08 |
| 100 | 20.11 | 19.78 | 44.3 | 42.3 | 28 | 25 |
| 200 | 18 | 28.97 | 39.78 | 37.78 | 21.98 | 18.98 |
| 250 | 17.32 | 32.84 | 38.33 | 36.33 | 20.04 | 17.04 |
| Conductor material | CCA, BC Copper |
|---|---|
| Conductor diameter | Solid: 0.4mm, 0.45mm, 0.5mm Stranded: 24 AWG, 26 AWG, 28 AWG |
| Number of Conductors | 2P, 4P, 8P, 10P, 25P, 50P, 100P, 200P, etc. |
| Insulation material | PE, HDPE |
| Insulation diameter | 0.9±0.02mm |
| Jacket material | PVC, ROHS PVC, LSZH PVC |
| Conductor material | CCA, BC Copper |
|---|---|
| Conductor diameter | Solid: 0.5mm, 0.56mm, 0.57mm Stranded: 23AWG, 24 AWG |
| Number of Conductors | 2P, 4P, 8P, 10P, 25P, 50P, 100P, 200P, etc. |
| Insulation material | PE, HDPE |
| Insulation diameter | 0.9±0.02mm |
| Jacket material | PVC, ROHS PVC, LSZH PVC |
